690 TVL Outdoor Vandal-Resistant True WDR, True Day/Night IR Dome


  • High Resolution 690 TVL
  • 1/3” PIXIM High sensitivity digital sensor
  • 3.3-12mm computar® IR coated auto-iris varifocal lens
  • 30 IR LEDS provide over 100’ illumination range
  • IR LED unit rotates to adjust IR direction
  • 3-axis manual pan/tilt rotation bracket
  • True Wide Dynamic Range, True Day/Night
  • Multi-function Tact switch for OSD control
  • Backlight / Highlight compensation
  • Motion detection
  • Privacy masking
  • 3D Digital noise reduction
  • Lens shading compensation
  • 12VDC or 24VAC operation, UL Listed
  • 3/4” NPT side conduit hole
  • Indoor & outdoor 4S Gang box mountable
  • Optional mounting accessories avaliable
  • IP67 Rating for all weather conditions
  • Meets UL standards


  • Companion Products contain accessories, options and additional products that work well with ZC-DWNT8312NBA-IR.
  • ZC8-FM2, ZC8-WM2A
